Methodology
Our firm’s methodology in London begins with a thorough desk study of existing geological maps, borehole records from the British Geological Survey, and historical ground conditions. This is followed by intrusive investigation, including spt boring in accordance with BS EN ISO 22476-3, to obtain disturbed and undisturbed samples. Laboratory testing, conducted in our soil mechanics laboratory, includes classification, strength, and consolidation tests to determine engineering parameters. Geophysical surveys, such as MASW and electrical resistivity, complement the boreholes. All data are integrated into a ground model that informs foundation design, slope stability, and earthworks, ensuring compliance with Eurocode 7 and local building regulations.
Reference Technical Parameters
| Parameter | Reference Value |
|---|---|
| Predominant soil type | Stiff overconsolidated clay (London Clay) with sand and gravel lenses |
| Typical groundwater level | 3–8 m below ground surface, locally perched |
| Bedrock depth | Chalk at 50–200 m depth; Lambeth Group at 20–40 m |
| Typical N60 range (SPT) | London Clay: 15–40 blows/0.3m; granular layers: 10–50 blows/0.3m |
| Maximum seismic acceleration (PGA) | 0.05–0.10 g (low seismicity, per UK National Annex to Eurocode 8) |
Local Considerations — London
London’s geology is dominated by the London Clay, a stiff, fissured clay prone to shrinkage and swelling with moisture changes, affecting shallow foundations and services. The groundwater regime is complex, with multiple aquifers—the Chalk, Thanet Sand, and River Terrace Deposits—often under artesian pressure, requiring depressurization during deep excavations. Seismic hazard is low, but site-specific assessments are needed for critical infrastructure. Ground conditions vary sharply between the City (deep alluvium and made ground) and the suburbs (shallow clay). Typical challenges include heave in deep basements, sulfate attack on concrete, and contamination from historical industrial use. Our slope stability analyses address cut slopes in clay and river embankments.
Request a Quote
Our team reviews your project and issues an initial report at no cost.
Or write us directly at [email protected]
Services in London
Locations covered in London
Applicable Standards
- Eurocode 7: Geotechnical design (BS EN 1997)
- Eurocode 8: Seismic design (BS EN 1998, UK National Annex)
- BS 5930: Code of practice for site investigations
- BS 8004: Code of practice for foundations
- ASTM D1586: Standard test method for SPT
Frequently Asked Questions
What are the typical soil types encountered in London?
London’s subsurface is predominantly London Clay, a stiff overconsolidated clay, overlying the Lambeth Group (clay, sand, and gravel) and Thanet Sand. River Terrace Deposits (gravel and sand) are common along the Thames. Made ground is widespread, especially in the City and Docklands.
Is seismic design required for buildings in London?
Yes, but the seismic hazard is low (peak ground acceleration <0.10 g). Eurocode 8 with the UK National Annex applies to structures in consequence classes 3 and 4, and to special structures. Most standard buildings do not require detailed seismic analysis, but site-specific response spectra may be needed for critical facilities.
Are geotechnical investigations mandatory for new developments in London?
Yes, under the Building Regulations 2010 (Part A) and local planning requirements, a site investigation is essential to establish ground conditions, groundwater levels, and contamination risks. The scope and depth depend on the project size, complexity, and ground hazards identified in a preliminary risk assessment.
